Efficiently Read Memory Cards with CCID Supported USB HD-100 Multi-function Card Reader
Product Details:
| Place of Origin: | Chongqing, China |
| Brand Name: | GS |
| Certification: | no |
| Model Number: | HD-100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pieces |
|---|---|
| Price: | $90.00/pieces 100-499 pieces |
| Packaging Details: | Standard Carton Box |
| Supply Ability: | 5000 Piece/Pieces per Month |
|
Detail Information |
|||
| Type: | Other Type | Interface: | Usb |
|---|---|---|---|
| Card Slots: | Single | Installation: | External |
| Material: | ABS, Plastic, ABS Plastic | Product Name: | Factory Directly USB HD-100 Multi-function Card Reader |
| Support Cards: | Contact/non-contact | Color: | White |
| Keywords: | Multi-function | Application: | Reading Stripe Card |
| Feature: | Usb Drivers | Function: | Read Memory Card |
| Support: | HID,CCID,PC/SC | Standards: | ISO/IEC 14443 A/B/C |
| Port: | ChongQing | ||
Product Description
1. Support ISO/IEC 7816-1/2/3 contact CPU card, ISO/IEC 14443-A/B/C contactless card, ISO/IEC 7811 magnetic stripe card, ID card
2. Support 4 PSAM card security modules and support high-speed PSAM card security transaction authentication
3. Contact card communication rate supports up to 307200bps, non-contact card communication rate up to 424Kbps
4. Full-speed USB interface, easy to install, no need to install additional drivers, easy to operate
5. Support online program upgrade, provide application standard DLL dynamic library interface under various platforms such as Windows/Linux/Unix
2. Support 4 PSAM card security modules and support high-speed PSAM card security transaction authentication
3. Contact card communication rate supports up to 307200bps, non-contact card communication rate up to 424Kbps
4. Full-speed USB interface, easy to install, no need to install additional drivers, easy to operate
5. Support online program upgrade, provide application standard DLL dynamic library interface under various platforms such as Windows/Linux/Unix
model | HD-100 |
Main processor | 32-bit processor, frequency 72MHz, industrial grade |
Contact card reader module | Support standard:ISO/IEC 7816 1/2/3 standard |
Card category: contact CPU card, logic encryption card 4442/4428, Memory card, etc. | |
Support rate: 9600 ~ 307200bps | |
Protection mechanism: short circuit protection, protection for any contacts and short circuit | |
Number of card slots: 2 standard embedded SAM card slots | |
Card insertion life: more than 100,000 times | |
Contactless card reader module | Supporting standards: ISO/IEC 14443 A/B/C standard |
Card type: Mifare One, contactless A, B card | |
Support rate: 106~424Kbps | |
Card reading distance: greater than 5CM | |
Magnetic stripe reading module | Support standard: ISO/IEC 7811 |
Support for tracks: 1/2 track or 2/3 track | |
Swipe direction: two-way | |
USB | Support HID, CCID, PC/SC protocol, support analog keyboard output protocol communication rate 12Mbps length 1.5 meters, with magnetic ring |
Serial port (optional) | Support standard RS232 interface, 485 interface communication rate support 9600~115200bps |
Power supply | DC5V±5%, USB power, standby 30mA, working current 250mA |
Short circuit protection | reverse polarity protection, over current protection, short circuit protection |
Working environment | temperature -20 ° C ~ 105 ° C humidity 5% ~ 90% without condensation |
Indicator light power | Highlight red Communication: Highlight green |
